sc_build_dll

Automated Sierra Chart Study Compilation Engine for Linux Environments. sc_build_dll is a high-performance Rust-based tool designed to streamline the development of Sierra Chart studies on Linux. It orchestrates the cross-compilation of ACSIL C++ source files into 64-bit Windows DLLs and handles the deployment and reloading process within Sierra Chart.

Background & Legacy Support

sc_build_dll is the official Rust-based successor to the original sc_build_dll.bash script. While the Bash version served me well for years, this Rust implementation is a direct upgrade that provides:

• Better Configuration: Profile-based management instead of hardcoded paths.
• Improved Robustness: Superior error handling and pre-deployment lock verification.
• Zero Dependencies: Compiles to a standalone binary (excluding the MinGW toolchain).

The original script is still available in the legacy/ directory for historical reference or specialized use cases.

Key Features

• Cross-Compilation: Uses MinGW-w64 to compile Windows DLLs directly from Linux.
• Cross-Platform Compatibility: Natively compiles on Windows systems using local GCC/MinGW-w64, maintaining identical command-line and configuration functionality.
• Profile Management: Support for multiple environment profiles (Sierra Chart installations) via a simple TOML configuration.
• Automated Deployment: Automatically copies the compiled DLL to your Sierra Chart Data directory.
• Hot-Reloading: Communicates with Sierra Chart via UDP to release the file lock and trigger an immediate reload of the study.
• Smart Retries: Waits for Sierra Chart to release file locks before attempting deployment.

Prerequisites

• Rust & Cargo: Installed via rustup.rs (or your system's package manager).
• C++ Compiler (GCC/g++):
  • For Linux Users (Primary): x86_64-w64-mingw32-g++ cross-compiler.
    • On Arch based Linux distros: sudo pacman -S mingw-w64-gcc
    • On Ubuntu/Debian: sudo apt install g++-mingw-w64-x86-64
  • For Windows Users (Secondary): g++ local compiler added to your system PATH. Installation options:
    • Scoop (Recommended / Cleanest): Run scoop install mingw in PowerShell (automatically configures your PATH).
    • WinLibs (Easiest Standalone ZIP): Download the lightweight compiler ZIP from winlibs.com and manually add the extracted bin/ folder to your System environment variable PATH.
    • MSYS2 (Full Shell Environment): Install MSYS2 from msys2.org, run pacman -S mingw-w64-ucrt-x86_64-gcc in the UCRT64 terminal, and add C:\msys64\ucrt64\bin to your system PATH.
  • For macOS Users (Untested): It should theoretically work using a cross-compiler (e.g., mingw-w64 installed via Homebrew: brew install mingw-w64) if you are running Sierra Chart under Wine, but I have not tested this setup. Feedback is welcome!
• Sierra Chart: Running with the UDP server enabled.

Installation

Pre-compiled Binaries (Recommended)

If you do not want to compile the tool from source, you can download pre-compiled static binaries directly from the Releases page.

The latest release and its compiled assets (supporting both Linux and Windows) will always be displayed at the very top of that page.

From Source

git clone https://git.thelonestack.com/thelonestack/sc_build_dll_rust.git
cd sc_build_dll_rust
make install

This will build the release binary and install it to ~/.local/bin/sc_build_dll. It also sets up a default configuration file in ~/.config/sc_build_dll/sc_build.toml.

Configuration

The tool searches for sc_build.toml in the current directory first, then in ~/.config/sc_build_dll/.

Example sc_build.toml

# Linux Profile Example:
[profiles.dev]
sc_dir = "/home/user/.cxoffice/SierraChart_DEV/drive_c/SierraChart"
udp_port = 8889
cxx_flags = "-w -s -O2"

# Windows Profile Example (uses single quotes to avoid escaping backslashes):
[profiles.win]
sc_dir = 'C:\SierraChart'
udp_port = 8890
cxx_flags = "-O2 -s -Wno-deprecated"

• sc_dir: The root directory of your Sierra Chart installation (absolute Linux path, or Windows path like 'C:\SierraChart'). Note: on Windows, use single quotes (') to avoid having to double-escape backslashes.
• udp_port: The UDP port configured in Sierra Chart under Global Settings >> Remote Chart Control/UDP Port.
• cxx_flags: Compiler configuration flags. If defined, these flags completely customize the release compilation behavior. The recommended default is "-O2 -s -Wno-deprecated". In debug mode (via the --debug flag), these flags are still processed, but any strip flags (-s) are automatically filtered out and optimization levels are overridden by -O0 to preserve debugging symbols.

Usage

Basic compilation and deployment:

sc_build_dll MyStudy.cpp

Using a specific profile:

sc_build_dll --profile real MyStudy.cpp

Debug build (includes -g, disables aggressive optimizations, and enforces frame pointers):

sc_build_dll --debug MyStudy.cpp

Verbose output (useful for troubleshooting):

sc_build_dll --verbose MyStudy.cpp

Native Windows Support (Optional)

Although sc_build_dll is primarily designed to simplify compilation workflows in Linux-to-Wine environments, it works natively on Windows.

When running on Windows:

1. The tool automatically resolves compiler execution to g++ instead of the cross-compiler.
2. In your sc_build.toml configuration, use single quotes (') for Windows folder paths to avoid needing double backslashes. For example:

   [profiles.dev]
   sc_dir = 'C:\SierraChart'
   udp_port = 8889


How it Works

1. Configuration Loading: Reads the specified profile from sc_build.toml.
2. MinGW Compilation: Invokes the compiler (e.g., g++) with mandatory Sierra Chart flags (following the official recommended flags from Sierra Chart Support Board Post ID 403507) and include paths for ACS_Source.
3. Unlock Command: Sends a RELEASE_DLL command via UDP to Sierra Chart.
4. Lock Verification: Polls the target file path in the Sierra Chart Data directory until it is writable.
5. Deployment: Copies the freshly compiled *_64.dll to the Data directory.
6. Reload Command: Sends an ALLOW_LOAD_DLL command via UDP to Sierra Chart to trigger the study reload.

Editor Integration

VS Code / VSCodium

If you develop in Visual Studio Code (consider switching to VSCodium! It is a community-driven, telemetry-free alternative), a pre-configured tasks.json is provided in the repository under contrib/vscode/tasks.json to automate compilation.

To use it:

1. Create a .vscode folder in the root of your C++ study project workspace.
2. Copy the file from contrib/vscode/tasks.json into .vscode/tasks.json.
3. Customize the configuration in .vscode/tasks.json to match your local environment:
   • command: Update this to the actual path of your sc_build_dll binary (or simply sc_build_dll if the executable is already added to your system PATH).
   • options (under inputs): Change the list of dropdown options (currently dev, real, win) to match the profile names defined in your local sc_build.toml.
4. Open any of your custom study .cpp files in VS Code and press Ctrl + Shift + B to execute the task.

License

MIT - See LICENSE for details.

---

Created by The Lone Stack.
